A30C
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 11036725 |
Companion flange | 1 |
| 2 | 11050946 |
Washer | 2 |
| 3 | 13968056 |
Screw | 6 |
| 4 | 11056257 |
Bearing cover | 1 |
| 5 | 13965192 |
Screw | 12 |
| 6 | 13965194 |
Screw | 6 |
| 7 | 4861316 |
Spacer ring | 6 |
| 8 | 959043 |
Sealing ring | 3 |
| 9 | 11055294 |
Ball bearing | 1 |
| 10 | 4821457 |
Protecting plate | 1 |
| 11 | 4943598 |
Bearing seat | 1 |
| 12 | 11050942 |
Countershaft | 1 |
| 13 | 11055347 |
Sealing retainer | 1 |
| 14 | 11056258 |
Roller bearing | 1 |
| 15 | 925276 |
O-ring | 1 |
| 16 | 11056606 |
Cover | 1 |
| 17 | 11102715 (1523543) |
Companion flange | 1 |
| 382015 |
•Dust cover | 1 | |
| 18 | 4970420 |
Press screw | 12 |
| 19 | 479979 (191026) |
Plug | 2 |
