A30C
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 11056294 |
Exhaust pipe | 1 |
| 2 | 11056190 (1508850) |
Clamp | 1 |
| 3 | 1577704 |
Sealing ring | 1 |
| 4 | 13965179 |
Screw | 2 |
| 5 | 948645 (948645) |
Flange lock nut | 2 |
| 6 | 591247 |
Sealant | 1 |
| 7 | 924064 |
Stud | 6 |
| 8 | 1545844 |
Diffuser | 1 |
| 9 | 13949873 |
Spacer washer | 6 |
| 10 | 949870 |
Tab washer | 3 |
| 11 | 946330 |
Hexagon nut | 6 |
| 12 | 8193567 (478089) |
Shutter housing | 1 |
| 13 | 467310 |
Clamp | 2 |
| 14 | 13965179 |
Screw | 2 |
| 15 | 948645 |
Flange lock nut | 2 |
| 16 | |
Regulator | 1 |
| 17 | 954356 |
Fitting nut | 1 |
| 18 | 954364 |
Ferrule | 1 |
| 19 | 948525 |
Hose assembly | 1 |
| 20 | 11055785 |
Anchorage | 1 |
| 21 | 13965186 |
Screw | 1 |
| 22 | 13971098 |
Flange nut | 1 |
| 23 | 192272 |
Lock nut | 1 |
| 24 | 13945460 |
Plastic pipe | REQ |
| 25 | 954356 |
Fitting nut | 2 |
| 26 | 954364 |
Ferrule | 2 |
| 27 | 944717 |
Sleeve | 2 |
| 28 | 4881440 |
Cable tie | 4 |
| 29 | 11055502 |
Plate | 1 |
| 30 | 969420 |
Six point socket screw | 4 |
| 971319 |
Six point socket screw | ||
| 31 | 8158342 (1608059) |
Solenoid valve | 1 |
| 32 | 13947282 |
Gasket | 3 |
| 957175 |
Gasket | ||
| 33 | 960629 |
Plug | 1 |
| 34 | 6626873 |
Fitting | 2 |
| 957175 |
•Gasket | 2 | |
| 35 | 13945460 |
Plastic pipe | REQ |
| 36 | 180084 |
T-nipple | 1 |
| 37 | 11052473 (11055532) |
Bracket | 1 |
| 38 | 11039223 |
Induction sensor | 1 |
| 39 | 13948297 |
Tab housing | 1 |
| 40 | 965824 (13968015) |
Cable terminal | 3 |
| 41 | 11039067 |
Bushing | 1 |
| 42 | 13945460 |
Plastic pipe | |
| 43 | 11062093 |
Fitting | |
| 44 | 957178 |
Gasket | - |
