| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | |
Oil pump | 1 |
| 2 | 955538 |
Hexagon screw | 4 |
| 3 | 13942336 |
Spring washer | 4 |
| 4 | 11031197 |
Suction pipe | 1 |
| 5 | 470383 |
Sealing ring | 2 |
| 6 | 13946173 |
Screw | 2 |
| 7 | 11031290 |
Bracket | 1 |
| 8 | 955531 |
Hexagon screw | 2 |
| 8A | 13955894 |
Washer | 2 |
| 9 | 11031206 |
Clamp | 1 |
| 10 | 13946544 |
Screw | 1 |
| 11 | 11031199 |
Suction pipe | 1 |
| 12 | 470383 |
Sealing ring | 2 |
| 13 | 13941678 |
Hexagon screw | 2 |
| 13A | 13955894 |
Washer | 2 |
| 14 | 977743 |
Clamp | 1 |
| 15 | 11053913 |
Spacer sleeve | 1 |
| 16 | 13940159 |
Screw | 2 |
| 17 | 13941907 |
Washer | 2 |
| 18 | 11031202 |
Anchorage | 1 |
| 19 | 11031203 |
Anchorage | 1 |
| 20 | 13946544 |
Screw | 2 |
| 21 | 942402 |
Flange screw | 2 |
| 22 | 4778338 |
Flange | 1 |
| 23 | 13949657 |
O-ring | 1 |
| 24 | 13965216 |
Screw | 2 |
| 25 | 865224 |
Tube | 1 |
| 26 | 470377 |
Connector | 1 |
| 27 | 956973 |
Ferrule | 1 |
| 28 | 466908 |
Fitting | 1 |
| 29 | 4778425 |
Pipe | 1 |
| 29A | 4778427 |
Flange | 1 |
| 30 | 13941678 |
Hexagon screw | 2 |
| 30A | 13955894 |
Washer | 2 |
| 31 | 7190159 |
Clamp | 1 |
| 32 | 11053913 |
Spacer sleeve | 1 |
| 33 | 955525 |
Hexagon screw | 1 |
| 34 | 471707 |
Reduction valve | 1 |
| 35 | 469846 |
Sealing ring | 1 |
| 36 | 949658 |
O-ring | 1 |
| 37 | 471752 |
Cover | 1 |
| 38 | 940100 |
Hexagon screw | 2 |
| 39 | 13949607 |
Washer | 2 |
| 40 | |
Oil sump | 1 |
