A30C
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 479650 |
Cylinder block | 1 | |
| 8194668 |
Cylinder block | ||
| 1 | |
•Cylinder block | 1 |
| |
•Cylinder block | ||
| 2 | |
•Cap | 7 |
| 3 | 422426 |
•Pin | 1 |
| 4 | 422067 (7422067) |
•Screw | 14 |
| 5 | 422076 |
•Bushing | 1 |
| 6 | 422077 |
•Bushing | 1 |
| 7 | 422078 |
•Bushing | 1 |
| 8 | 11000014 |
•Bushing | 1 |
| 9 | 422080 (7422080) |
•Bushing | 1 |
| 10 | 422081 |
•Bushing | 1 |
| 11 | 422082 |
•Bushing | 1 |
| 12 | 467367 |
•Plug | 5 |
| 13 | 821335 |
•Plug | 1 |
| 14 | 1556907 (469328) |
•Gasket | 6 |
| 15 | 952075 |
•Plug | 1 |
| 16 | 422369 |
•Plug | 7 |
| 17 | 191171 (7191171) |
•Pin | 2 |
| 18 | 13955083 |
•Cap plug | 2 |
| 19 | 955082 |
•Cap plug | 4 |
| 20 | 14025455 |
•Cylinder Pin | 12 |
| 21 | 479977 |
•Plug | 3 |
| 8194662 |
•Plug | ||
| 13947622 (7011996) |
•Plane gasket | ||
| 22 | 479979 |
•Plug | 7 |
| 13947814 |
•Plug | 1 | |
| 23 | 13961892 |
•Plug | 1 |
| 24 | 13947621 |
•Plane gasket | 1 |
| 25 | |
•Pipe | 1 |
| 26 | 424715 |
•Plug | 1 |
| 27 | 13949657 |
•O-ring | 1 |
| 28 | 424714 |
•Flange | 1 |
| 29 | 955513 |
•Hexagon screw | 2 |
| 30 | 13941906 |
•Washer | 2 |
| 31 | |
•Pipe | 1 |
| |
•Pipe | ||
| 32 | 424801 |
•Tube | |
| 8125388 |
Piston cooling valve | 1 | |
| 33 | 13949656 |
O-ring | 1 |
| 34 | 479954 |
Nipple | 1 |
| 35 | 997641 (13949918) |
Shut-off Cock | 1 |
| 36 | 11039249 |
Pressure monitor | 1 |
| 11039575 |
Pressure sensor | 1 | |
| 11039575 |
Pressure sensor | 1 | |
| 37 | 422322 |
Lifting eye | 3 |
| 38 | 940280 |
Spring washer | 6 |
| 39 | 955561 |
Hexagon screw | 6 |
| 40 | 423120 |
Hatch | 2 |
| 41 | 423121 |
Hatch | 1 |
| 42 | 422542 |
Splash plate | 1 |
| 43 | 469823 |
Gasket | 3 |
| 44 | 422541 |
Screw | 6 |
| 45 | 471856 |
Sealing ring | 6 |
| 46 | 180761 |
Plug | 1 |
| 47 | 13947622 (7011996) |
Plane gasket | 1 |
| 48 | 864374 |
Piston cooling jet | 6 |
| 49 | 13948587 |
Lock screw | 6 |
| 50 | 180761 |
Plug | 1 |
| 51 | 13947622 (7011996) |
Plane gasket | 1 |
