WHEEL LOADER VOLVO L250G
BASIC MACHINE
PROD NO. 33014, L250G, S/N 1002 - 1121
PROD NO. 33014, L250G, S/N 3004 - 3260
CAB
PROD NO. 11294051
TRANSMISSION
PROD NO. 22581, HTL307
DRIVE AXLES
PROD NO. 56037, AWB 50, front
PROD NO. 23967, AWB 41, rear
PROD NO. 23968, AWB 41, rear. 84377
LOADER UNIT
PROD NO. 33860, LU L250G LUB
PROD NO. 33040, LU L250G LB, 84810
MOTOR
Part number 15049439, D13H-E, (15173113, D13H, AME/After market engine), 85420
Part number 15117870, D13H-F, (15173113, D13H, AME/After market engine), 85421
Part number 15049437, D13F-C, (15173114, D13F, AME/After market engine), 85424
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 968298 |
Flange screw | 4 |
| 2 | 866395 |
Spacer | 4 |
| 3 | 943372 |
Hose | 1 |
| 4 | 993974 |
Hose clamp | 10 |
| 5 | 16811979 |
Water pipe | 1 |
| 6 | 946173 |
Flange screw | 1 |
| 7 | 948645 |
Flange lock nut | 1 |
| 8 | 11061686 |
Radiator hose | 1 |
| 9 | 15135094 |
Heat exchanger | 1 |
| 10 | 15161985 |
Water hose | 1 |
| 11 | 15160809 |
Water pipe | 1 |
| 12 | 946544 |
Flange screw | 3 |
| 13 | 960139 |
Plain washer | 3 |
| 14 | 949278 |
Flange lock nut | 3 |
| 15 | 15161968 |
Water hose | 1 |
| 16 | 11015455 |
Flange half | 4 |
| 17 | 959239 |
Hex. socket screw | 8 |
| 18 | 990756 |
Sealing ring | 2 |
| 19 | 15138563 |
Hose assembly | 1 |
| 20 | 15138691 |
Hose assembly | 1 |
| 21 | 11130090 |
Nipple | 2 |
| 22 | 11130091 |
O-ring | 2 |
| 23 | 11411501 |
Nipple | 2 |
| 24 | 11411425 |
Clamp | 3 |
| 25 | 4880586 |
Cover plate | 3 |
| 26 | 965180 |
Flange screw | 3 |
| 27 | 943471 |
Hose clamp | 1 |
| 28 | 11445063 |
Drain hose | 1 |
| 29 | 977599 |
Clamp | 1 |
| 30 | 946173 |
Flange screw | 1 |
| 31 | 11130271 |
Clamp | 1 |
| 32 | 949278 |
Flange lock nut | 2 |
| 33 | 965191 |
Flange screw | 2 |
| 34 | 11055607 |
Plain washer | 2 |
| 35 | |
Water Hose | 1 |
| 36 | 15180563 |
Radiator seal | 1 |
| 37 | 946441 |
Flange screw | 2 |
| 38 | 15180863 |
Sealing strip | REQ |
| 39 | 968893 |
Flange screw | 2 |
| 40 | 969354 |
Clamp | 1 |
| 41 | 15122123 |
Tensioning plate | 1 |
