A35C

Hemen bizi arayın yardımcı olalım

SEÇ/NO	PARÇA KOD	PARÇA ADI	PARÇA SAYISI
1	11037704	Engaging sleeve	1
2	184696	Ball bearing	1
3	951081	Snap ring	1
4	4837070	Spacer washer	REQ
	4837071	Spacer washer	REQ
	4837072	Spacer washer	REQ
	11036473	Spacer washer	REQ
	4837073	Spacer ring	REQ
5	184373	Thrust needle roller assy	2
6	184836	Roller bearing	1
7	11037707	Differential housing	1
8	4837041	Differential side gear	1
9	11145164 (11036524)	Spider	1
10	6630855	Differential pinion set	1
11	4720606	Spacer ring	8
12	4720541	Needle bearing	164
13	4720616	Thrust washer	4
14	4837042	Differential side gear	1
15	184286	Housing washer	1
16	4837040	Differential housing	1
17	959267	Hex. socket screw	16
18	184628	Roller bearing	1
19	11036778	Bearing cover	1
20	968241	O-ring	1
21	4720865	Piston ring	1
22	11036781	Shim	REQ
	11036782	Shim	REQ
	11036783	Shim	REQ
23	970976 (13970976)	Hexagon screw	8
24	13949608	Washer	8
25	914492	Snap ring	1
26	11037911	Gear	1
27	795307	Piston ring	1
28	11036472	Tubular shaft	1
29	184722	Roller bearing	2
30	4837067	Spacer ring	1
31	968243	Retaining ring	1
32	11037438	Shaft	1
33	4719964	•Companion flange	1
34	184348	Thrust needle roller assy	1
35	968244	Snap ring	1
36	4837081	Thrust washer	1
37	7011071	Roller bearing	2
38	13949736	O-ring	1
39	11036784	Shim	REQ
	11036785	Shim	REQ
	11036786	Shim	REQ
40	11036779	Bearing housing	1
41	13970948	Hexagon screw	5
42	941908	Spring washer	5
43	15053734 (11038338)	Sealing ring	1
44	1523124	Sealing ring	1
45	11036503	Companion flange	1
46	11036863	Washer	1
47	13968056	Screw	3
