YM Güç Tork - 464/200 Hub reduction, axle 2 load unit AH64F PROD NO 23911 - A30D

SEÇ/NO	PARÇA KOD	PARÇA ADI	PARÇA SAYISI
1	23911	Planetary Axle	1
	4870181	•Spindle	2
3	980827	•O-ring	2
4	4870321	•Brake anchorage	2
5	4717661	•Hex. socket screw	18
	949566	•Hex. socket screw	18
6	11103095	•Brake	2
7	4717660	•Screw	12
8	941914	•Spring washer	12
9	17232908 (11034281)	•Brake disc	2
10	13960248	•O-ring	2
11	11103222 (11103096)	•Spacer ring	2
	11103222	•Spacer ring	2
	15198512	•Spacer ring	2
12	11103124 (11102687)	•Sealing ring	2
	11103124	•Sealing ring	2
13	17488188 (183690)	•Bearing	2
14	15123158	•Wheel stud	24
15	967691	•Hex. socket screw	24
16	11034715	•Hub	2
	17232928 (11103102)	•Hub	2
17	183749	•Roller bearing	2
18	4717022	•Snap ring	4
19	4717383	•Gear ring holder	2
20	17246170 (4717070)	•Gear ring	2
21	11102364	•Nut	2
22	4870108	•Lock ring	2
23	4870109	•Lock ring	2
24	945506	•Snap ring	2
25	11103086	•Drive shaft	1
26	11103085	•Drive shaft	1
27	11102909	•Thrust washer	2
28	11102298	•Sun gear	2
29	945499	•Snap ring	2
30	11102910	•Wear ring	2
31	11102677	•Planet carrier	2
	11103250	•Planet carrier	2
	11035031	•O-ring	2
32	4880969	•Roller bearing	6
	11034200	•Washer	12
33	11102297	•Planet gear	6
34	4870486	•Thrust washer	12
35	11034147	•Thrust washer	12
36	11034889	•Planetary Gear Shaft	6
37	4870445	•Striker plate	6
38	4870448	•Screw	12
39	11034156	•Plug	4
	11034156	•Plug	2
40	958228	•O-ring	4
	958228	•O-ring	2
41	952031	•Spring pin	8
42	951990	•Spring pin	8
43	13977564	•Hexagon screw	48
	980238	•Hex. socket screw	56
