A25C
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 1526537 |
Control | 1 |
| 2 | |
Shim | 1 |
| 11058163 |
Cover plate | 1 | |
| 3 | 13945294 |
O-ring | 1 |
| 4 | 956066 |
Cros recessed | 2 |
| 5 | 13941904 |
Washer | 2 |
| 6 | 955779 |
Hexagon nut | 2 |
| 7 | 11062302 |
Direction valve | 1 |
| 8 | 980830 |
Plastic pipe | REQ |
| 9 | 267224 |
Plug | 1 |
| 10 | 955980 |
O-ring | 2 |
| 11 | 4940755 |
Nipple | 2 |
| 12 | 954364 |
Ferrule | REQ |
| 13 | 954356 |
Fitting nut | REQ |
| 14 | 944717 |
Sleeve | REQ |
| 15 | 13945915 |
Elbow nipple | 2 |
| 16 | 13945460 |
Plastic pipe | REQ |
| 17 | 13945460 |
Plastic pipe | REQ |
| 18 | 13945460 |
Plastic pipe | REQ |
| 19 | |
Cylinder | 1 |
| 20 | 944364 |
O-ring | 2 |
| 21 | 13945892 |
Nut | 2 |
| 22 | 6626874 |
Clutch | 1 |
| 23 | 13945460 |
Plastic pipe | REQ |
| 24 | 13945460 |
Plastic pipe | REQ |
