A25C
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | |
Filter Housing | 1 |
| 2 | 13949656 |
O-ring | 2 |
| 3 | 13949722 |
O-ring | 1 |
| 4 | 946329 |
Flange screw | 2 |
| 13965222 |
Screw | 1 | |
| 5 | 941908 |
Spring washer | 3 |
| 6 | 4771601 |
Plate | 1 |
| 7 | 968759 |
O-ring | 1 |
| 8 | 914461 |
Retaining ring | 1 |
| 9 | |
Nipple | 1 |
| 10 | 21707134 (466634) |
Oil Filter | 1 |
| 21707133 (478736) |
Oil filter | 1 | |
| 11 | 946471 |
Flange screw | 1 |
| 12 | 13971074 |
Hexagon nut | 1 |
| 13 | 835980 |
Nipple | 1 |
| 14 | 1606877 |
Switch | 1 |
| 15 | 848319 |
Plug | 1 |
| 16 | 22194880 (421629) |
Sealing ring | 1 |
| 17 | |
Attachment | 1 |
| 18 | 946440 |
Flange screw | 1 |
| 19 | 471602 |
Tube | 1 |
| 20 | 471956 |
Sealing ring | 2 |
| 21 | |
Housing | 1 |
| 22 | 13949656 |
O-ring | 2 |
| 23 | 946329 |
Flange screw | 3 |
| 24 | 941908 |
Spring washer | 3 |
| 25 | |
Nipple | 1 |
| 26 | 21707132 (477556) |
Oil filter | 1 |
