WHEEL LOADER VOLVO L90E
BASIC MACHINE
PROD NO 33278, SER NO 20001 -
PROD NO 33278, SER NO 66001 - USA
PROD NO 33278, SER NO 70801 - BRAZIL
PROD NO 33286 OPEN ROPS, SER NO 72201 - BRAZIL
PROD NO 33288, SER NO 42001 - IRAN
CAB
PROD NO 33277
PROD NO 33284 CAB USA (82410)
PROD NO 33287 OPEN ROPS
TRANSMISSION
PROD NO 22523, HTE202, SER NO - 20095
SER NO - 66019 USA,
SER NO - 70802 BRAZIL
PROD NO 22548, HTE202, SER NO 20096 -
SER NO 66020 - USA
SER NO 70803 - BRAZIL
DRIVING AXLE
PROD NO 23919, AWB 25, front
PROD NO 23920, AWB 20, rear
LOADING UNIT
PROD NO 33282
ENGINE
Part No 11172408, Typ VOLVO D6DLAE2
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 23919 |
Planet shaft | 1 | |
| 11168100 |
•Drive gear set | 1 | |
| 1 | |
••Crown wheel | 1 |
| 2 | |
••Drive pinion | 1 |
| 3 | 11102623 |
•Spider | 1 |
| 11103110 |
•Diff Gear Kit | 1 | |
| 4 | 17415136 (1069849) |
••Differential side gear | 2 |
| 5 | 1524587 |
••Differential side gear | 4 |
| 6 | 17203766 (11102049) |
•Thrust washer | 4 |
| 7 | 11102146 |
•Thrust washer | 2 |
| 8 | 11168105 |
•Differential housing | 1 |
| 9 | 11168106 |
•Screw | 14 |
| 10 | 13946008 |
•Lock nut | 14 |
| 11 | 11168134 (11168104) |
•Differential housing | 1 |
| 11168134 |
•Differential housing | 1 | |
| 12 | 11168106 |
•Screw | 14 |
| 13 | 183704 |
•Roller bearing | 1 |
| 14 | 184637 |
•Roller bearing | 1 |
| 15 | 11168063 |
•Shim | REQ |
| 11168064 |
•Shim | REQ | |
| 11168065 |
•Shim | REQ | |
| 16 | 11168060 |
•Shim | REQ |
| 11168061 |
•Shim | REQ | |
| 11168062 |
•Shim | REQ | |
| 17 | 11035994 |
•Roller bearing | 2 |
| 18 | 11034695 |
•Shim | REQ |
| 11034696 |
•Shim | REQ | |
| 11034697 |
•Shim | REQ | |
| 19 | 11034828 |
•Spacer ring | REQ |
| 11034829 |
•Spacer ring | REQ | |
| 11034830 |
•Spacer ring | REQ | |
| 11034831 |
•Spacer ring | REQ | |
| 4870247 |
•Spacer ring | REQ | |
| 4870248 |
•Spacer ring | REQ | |
| 4870249 |
•Spacer ring | REQ | |
| 4870250 |
•Spacer ring | REQ | |
| 20 | 17221241 (184660) |
•Roller bearing | 1 |
| 21 | 4717576 |
•Sealing ring | 1 |
| 22 | 943142 |
•Sealing ring | 1 |
| 23 | 11168030 |
•Companion flange | 1 |
| 24 | 11168081 |
••Dust cover | 1 |
| 25 | 4717504 |
•Nut | 1 |
| 26 | 382779 |
•Lock washer | REQ |
| 27 | 383992 |
•Lock washer | REQ |
| 28 | 914480 |
•Snap ring | 1 |
