+90 552 671 32 12TRANSMISSION, HYDRAULIC CONTROL > 421/300 Clutches 1:st and 2:nd speeds 22524, 22536
WHEEL LOADER
VOLVO L90D
BASIC MACHINE
PROD NO 33266, L90D S/N 17001 - 18685
PROD NO 33266, L90D USA S/N 64001 - 64937
PROD NO 33266, L90D BRAZIL S/N 70501 - 70730
PROD NO 33266, L90D USA S/N 65001 - 65037
CAB
PROD NO 33264 Care Cab II
PROD NO 33279 (80842)SEMI OPEN CAB
TRANSMISSION
PROD NO 22524, HT131
DRIVING AXLE
PROD NO 23886, AWB 30, front
PROD NO 23887, AWB 30, rear
PROD NO 23889, AWB 30, rear Limited slip diff, 80516
LOADING UNIT
PROD NO 33267
ENGINE
Part No 8188107, Typ TD63 KBE. Low exhaust emission version.
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 11144015 |
Hydraulic clutch | 1 | |
| 1 | 11037128 |
•Clutch shaft | 1 |
| 2 | 11036107 |
••Partition wall | 1 |
| 3 | 4786535 |
••Lock ring | 2 |
| 3A | 184645 |
••Ball | 2 |
| 4 | 4871048 |
•Piston ring | 2 |
| 5 | 4720798 |
•Piston ring | 2 |
| 6 | 4720800 |
•Piston ring | 2 |
| 7 | 4873073 |
•Piston | 2 |
| 8 | 4871532 |
•Spring | 1 |
| 9 | 11037146 |
•Clutch hub | 1 |
| 10 | 4871533 |
•Spring | 1 |
| 11 | 11037154 |
•Clutch hub | 1 |
| 12 | 11037196 |
•Friction disc | 18 |
| 13 | 4720763 |
•Steel disc | 18 |
| 14 | 11037145 |
•Pressure plate | 2 |
| 15 | 11037147 |
•Lock ring | 2 |
| 16 | 4786536 |
•Lock ring | 2 |
| 17 | 4871337 |
•Retainer | 2 |
| 18 | 4880972 |
•Thrust washer | 2 |
| 19 | 4871338 |
•Thrust washer | 4 |
| 20 | 4785772 |
•Needle bearing | 4 |
| 21 | 11145380 |
•Needle holder | 1 |
| 22 | 4718468 |
•Spacer sleeve | 1 |
| 23 | 11144006 |
•Needle bearing | 1 |
| 24 | 11037141 |
•Gear | 1 |
| 25 | 4720774 |
•Gear | 1 |
| 26 | 4718008 |
•Washer | 1 |
| 27 | 15175558 (4718930) |
•Thrust washer | 1 |
| 28 | 13947902 |
•Lock ring | 1 |
| 183824 |
•Roller bearing | 1 | |
| 29 | 184731 |
••Cone | 1 |
| 30 | 183356 |
••Cup | 1 |
| 184727 |
•Roller bearing | 1 | |
| 31 | 184731 |
••Cone | 1 |
| 32 | 184732 |
••Cup | 1 |
| 33 | 4720797 |
•Piston ring | 3 |
