Wheel Loader Volvo L350F
BASE MACHINE
PROD NO 31713, L350F, SER NO 1001 -
CAB
PROD NO 31715
PROD NO 33027 S/N 1250-
TRANSMISSION
Part No. 11145759, HTE400
DRIVING AXLES
Part No. 11145757, Front axle
Part No. 11145761, Front axle. 82840
Part No. 11145758, Rear axle
Part No. 11145762, Rear axle. 82840, 82841
ENGINE
Engine number 8188182, D16ELAE3. S/N - 1087
Engine number 8188187, D16E. S/N 1088 -
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 21341905 (20742700) |
Cylinder block | 1 | |
| 21341905 (21168777) |
Cylinder block | ||
| 1 | |
•Cylinder Block | 1 |
| 1 | |
•Cylinder Block | |
| 2 | |
•Main Bearing Cap | 1 |
| 3 | |
•Main Bearing Cap | 4 |
| 4 | |
•Main Bearing Cap | 1 |
| 5 | |
•Main Bearing Cap | 1 |
| 6 | 8131967 |
•Guide Sleeve | 14 |
| 7 | 20581443 |
•Flange screw | 14 |
| 8 | 417588 |
Guide sleeve | 2 |
| 9 | 8131145 |
Guide sleeve | 2 |
| 10 | |
Plug | 2 |
| 10 | 13968610 |
•Plug | 2 |
| 11 | 13976109 |
•O-ring | 2 |
| 12 | 950588 |
Pin | 1 |
| 13 | 20485996 |
Guide sleeve | 2 |
| 14 | 20381177 |
Plug | 1 |
| 15 | 471708 |
Sealing ring | 1 |
| 16 | 1546531 (20844430) |
Lock brace | 1 |
| 17 | 946440 |
Flange screw | 1 |
| 18 | 24426721 |
Expansion plug | 2 |
| 19 | 8131937 |
Expansion plug | 4 |
| 20 | 960631 |
Plug | 1 |
| 21 | 13947622 |
Plane gasket | 1 |
| 22 | 20562189 |
Plug | 2 |
| 22 | |
•Plug | 2 |
| 23 | 466922 |
•Sealing ring | 4 |
| 24 | 13966378 |
Flange screw | 1 |
| 25 | 11117464 |
Plain washer | 1 |
| 26 | 960632 |
Plug | 1 |
| 27 | 21024032 |
Sealing ring | 1 |
| 28 | 960629 |
Plug | 1 |
| 29 | 13947282 |
Gasket | 1 |
| 30 | |
Yoke | 1 |
| 31 | 21940615 (1547255) |
Sealing ring | 1 |
| 32 | 20567779 |
Plug | 1 |
| 33 | 946440 |
Flange screw | 1 |
| 34 | 20722628 |
Frame | 1 |
| 35 | 975110 |
Flange screw | 13 |
