+90 552 671 32 12TRANSMISSION, HYDRAULIC CONTROL > 421/600 Hydraulic clutch, 3rd/4th speed 22703
WHEEL LOADER VOLVO L220H
BASIC MACHINE
Product number 33046, L220H, Serial number 2691
Product number 33046, L220H, Serial number 2735 -
Product number 33046, L220H, Serial number 7272 -
Product number 33046, L220H, Serial number 12104 -
CAB
Product number 11294122
DRIVE AXLES
Part number 56128, AWB 50, front
Part number 23967, AWB 41, rear
Part number 56129, AWB 41, rear. 86819
TRANSMISSION
Product number 22703, HTL310
LOADER UNIT
Product number 33863
Product number 33864
ENGINE
Product number 15185566
Replacement version 17433661
Product number 17461273
Replacement version 17469395
Product number 17461278
Replacement version 17469396
Product number 17461280
Replacement version 17469394
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 17463370 |
Hydraulic clutch | 1 | |
| 1 | 11038835 |
•Piston ring | 1 |
| 2 | 11038728 |
•Snap ring | 1 |
| 3 | 184692 |
•Roller bearing | 1 |
| 4 | 17232445 |
•Washer | 1 |
| 5 | 184347 |
•Thrust needle roller assy | 4 |
| 6 | 15163556 |
•Thrust washer | 4 |
| 7 | 17448989 |
•Gear | 1 |
| 8 | 11038372 |
•Needle bearing | 2 |
| 9 | 184243 |
•Bearing washer | 2 |
| 10 | 11037592 |
•Lock ring | 2 |
| 11 | 11418487 |
•Lock ring | 2 |
| 12 | 11418433 |
•Disc kit | 1 |
| 13 | 11419239 |
•Disc spring | 14 |
| 14 | 11418443 |
•Thrust washer | 2 |
| 15 | 11989802 |
•Sealing ring | 2 |
| 16 | 11418442 |
•Piston | 2 |
| 17 | 11145532 |
•Sealing ring | 2 |
| 18 | 11037637 |
•Ball | 2 |
| 19 | 17434099 |
•Clutch shaft | 1 |
| 20 | 11418432 |
•Disc kit | 1 |
| 21 | 17438327 |
•Gear | 1 |
| 22 | 11037562 |
•Thrust washer | 1 |
| 23 | 11037594 |
•Lock ring | 1 |
