+90 552 671 32 12TRANSMISSION, HYDRAULIC CONTROL > 421/150 Converter housing, gears and shafts
WHEEL LOADER VOLVO L180D
BASIC MACHINE
PROD NO 33820, Ser No 4001 - 4718
PROD NO 33820, Ser No 62001 - 62078 USA
CAB
PROD NO 33514, Care Cab II
TRANSMISSION
PROD NO 22527, HT220
PROD NO 22528, HT220R
DRIVING AXLE
PROD NO 23839, AWB 40, front
PROD NO 23852, AWB 40, front. 93464, 93522
PROD NO 23854, AWB 40, front. 93523
PROD NO 23841, AWB 40, rear
PROD NO 23853, AWB 40, rear. 93464
PROD NO 23856, AWB 40, rear. 94636
PROD NO 23875, AWB 40, rear. 93522, 93523
LOADING UNIT
PROD NO 33807
PROD NO 33810, 93438
ENGINE
Part No 8188162, Typ TD122 KHE. Low exhaust emission version.
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | |
Housing | 1 |
| 2 | 11037660 |
Shaft | 1 |
| 3 | 11037019 |
Piston ring | 1 |
| 4 | 11038386 |
Converter base | 1 |
| 5 | 11037299 |
Gasket | 1 |
| 6 | 184230 |
Housing washer | 1 |
| 7 | 184336 |
Roller and cage assembly | 1 |
| 8 | 184212 |
Shaft washer | 1 |
| 9 | 183124 |
Roller bearing | 1 |
| 10 | 13949905 |
Snap ring | 1 |
| 11 | 942140 |
Back-up ring | 1 |
| 12 | 11038728
(11037180) |
Snap ring | 1 |
| 13 | 11037843 |
Gear | 1 |
| 14 | 184721 |
Roller bearing | 1 |
| 15 | |
Hydraulic Pump | 1 |
| 16 | 959250 |
Hex. socket screw | 6 |
| 17 | 976945 |
Washer | 6 |
| 18 | |
Gear | 1 |
| 19 | 4720798 |
Piston ring | 1 |
| 20 | 13947902 |
Lock ring | 1 |
| 21 | 959241 |
Hex. socket screw | 3 |
| 22 | 11037273 |
Gear | 2 |
| 23 | 11037809 |
Roller bearing | 2 |
| 24 | 11037479 |
Snap ring | 2 |
| 25 | 11037807 |
Lock nut | 2 |
| 26 | 4780941 |
Induction sensor | 1 |
| 27 | 967750 |
O-ring | 1 |
