L180D
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
WHEEL LOADER VOLVO L180D
BASIC MACHINE
PROD NO 33820, Ser No 4001 - 4718
PROD NO 33820, Ser No 62001 - 62078 USA
CAB
PROD NO 33514, Care Cab II
TRANSMISSION
PROD NO 22527, HT220
PROD NO 22528, HT220R
DRIVING AXLE
PROD NO 23839, AWB 40, front
PROD NO 23852, AWB 40, front. 93464, 93522
PROD NO 23854, AWB 40, front. 93523
PROD NO 23841, AWB 40, rear
PROD NO 23853, AWB 40, rear. 93464
PROD NO 23856, AWB 40, rear. 94636
PROD NO 23875, AWB 40, rear. 93522, 93523
LOADING UNIT
PROD NO 33807
PROD NO 33810, 93438
ENGINE
Part No 8188162, Typ TD122 KHE. Low exhaust emission version.
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 270949 |
Gasket kit | 6 | |
| 273983 |
Repair kit | 6 | |
| 275634 |
Cylinder liner kit | 6 | |
| 270950 |
•Sealing kit | 6 | |
| 270603 |
•Piston ring kit | 6 | |
| |
Big end bearing kit | 6 | |
| |
Mn bearing kit | 7 | |
| |
Thrust washer kit | 1 | |
| 11031523 |
Gasket | 1 | |
| 275554 |
Gasket kit | 1 | |
| 424692 |
•Gasket | 6 | |
| 942580 |
•Gasket | 12 | |
| 423281 |
•Sealing ring | 6 | |
| 11700221 |
Overhaul kit | 1 | |
| 273873 |
Repair kit | 1 | |
| 11700108 |
Repair kit | 1 | |
| 11999354 |
Overhaul kit | 1 | |
| 275554 |
•Gasket kit | 1 | |
| 270949 |
•Gasket kit | 6 | |
| 470534 |
•Gasket | 6 | |
| 20784537 (470939) |
•Gasket | 1 | |
| 469662 |
•Gasket | 1 | |
| 8149182 |
•Thermostat | 2 | |
| 1544710 |
•Sealing ring | 2 | |
| 11000236 |
•Sealing ring | 2 | |
| 469830 |
•Rubber ring | 6 | |
11706304 |
Overhaul kit | 1 | |
| 275554 |
•Gasket kit | 1 | |
| 270949 |
•Gasket kit | 6 | |
| 275634 |
•Cylinder liner kit | 6 | |
| 270130 |
•Big End Brg Kit | 6 | |
| 270449 |
•Main bearing kit | 7 | |
| 21948261 (276791) |
•Thrust washer kit | 1 | |
| 11706270 |
•Gasket kit | 1 | |
| 420641 |
••Gasket | 1 | |
| 423352 |
••Gasket | 1 | |
| 424621 |
••Gasket | 1 | |
| 424692 |
••Gasket | 6 | |
| 469327 |
••Gasket | 12 | |
| 469486 |
••Gasket | 5 | |
| 469662 |
••Gasket | 1 | |
| 469823 |
••Gasket | 3 | |
| 470534 |
••Gasket | 6 | |
| 20784537 (470939) |
••Gasket | 1 | |
| 942580 |
••Gasket | 12 | |
| 942703 |
••Gasket | 2 | |
| 947620 |
••Gasket | 19 | |
| 949329 |
••Gasket | 1 | |
| 976929 |
••Gasket | 19 | |
| 1275379 (940096) |
••Gasket | 2 | |
| 13947624 (7011998) |
••Plane gasket | 2 | |
| 7018666 |
••Gasket | 1 | |
| 11031523 |
••Gasket | 1 | |
| 13947281 |
••Gasket | 13 | |
| 13947282 |
••Gasket | 3 | |
| 13947622 |
••Plane gasket | 1 | |
| 13947625 |
••Plane gasket | 2 | |
| 13947627 |
••Plane gasket | 1 | |
| 424580 |
••Seal | 1 | |
| 13947621 |
••Plane gasket | 2 | |
| 13947624 |
••Plane gasket | 2 | |
| 423057 |
••Sealing ring | 4 | |
| 423123 |
••Sealing ring | 1 | |
| 423281 |
••Sealing ring | 6 | |
| 424983 |
••Sealing ring | 1 | |
| 466405 |
••Sealing ring | 6 | |
| 468094 |
••Sealing ring | 1 | |
| 20441697 (469336) |
••Seal | 2 | |
| 469455 |
••Sealing ring | 6 | |
| 469483 |
••Sealing ring | 2 | |
| 469846 |
••Sealing ring | 1 | |
| 470323 |
••Sealing ring | 12 | |
| 470383 |
••Sealing ring | 4 | |
| 470527 |
••Sealing ring | 2 | |
| 471856 |
••Sealing ring | 7 | |
| 1542781 |
••Sealing ring | 1 | |
| 1542783 |
••Sealing ring | 1 | |
| 1544710 |
••Sealing ring | 3 | |
| 11000236 |
••Sealing ring | 1 | |
| 925059 |
••O-ring | 1 | |
| 925064 |
••O-ring | 1 | |
| 925257 |
••O-ring | 1 | |
| 944126 |
••O-ring | 4 | |
| 949658 |
••O-ring | 1 | |
| 949659 |
••O-ring | 2 | |
| 1664473 |
••O-ring | 2 | |
| 984470 (13943943) |
••O-ring | 1 | |
| 13949656 |
••O-ring | 1 | |
| 13949657 |
••O-ring | 1 | |
| 13975610 |
••O-ring | 1 | |
| 466420 |
••Ring | 6 | |
| 469830 |
••Rubber ring | 6 | |
| 941666 |
••Sealing ring | 1 | |
| 1545479 |
••Screw | 12 |
