WHEEL LOADER VOLVO L150E
BASIC MACHINE
PROD NO 33516, L150E, SER NO 6001 - 7549
PROD NO 33516, L150E, SER NO 63001 - 63085 USA
CAB
PROD NO 33517, CAB - 2666
TRANSMISSION
PROD NO 22535, HTE210
DRIVING AXLE
PROD NO 23881, AWB 40B, front
PROD NO 23894, AWB 40B, front, 80823
PROD NO 23882, AWB 40B, rear
PROD NO 23895, AWB 40B, rear, 80822, 80823
LOADING UNIT
PROD NO 33518, L150 LA
PROD NO 33519, L150 LA, long boom, 80701
ENGINE
Part No 8188146, D10 BLAE2
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 270946 |
Repair kit | 1 | |
| 479486 |
Gasket | 1 | |
| 276156 |
Repair kit | 1 | |
| |
|||
| 11711557 |
Gasket kit | 1 | |
| 270789 |
•Gasket kit | 1 | |
| 420641 |
•Gasket | 1 | |
| 420643 |
•Gasket | 1 | |
| |
|||
| 11711555 |
Overhaul kit | 1 | |
| 270789 |
•Gasket kit | 6 | |
| 11705058 |
•Cylinder liner kit | 6 | |
| 271157 |
••Sealing kit | 6 | |
| 276851 |
••Piston ring kit | 6 | |
| 270124 |
•Big End Brg Kit | 6 | |
| 270438 |
•Main bearing kit | 7 | |
| 276758 |
•Thrust washer kit | 1 | |
| 20441697 |
•Seal | 1 | |
| 276035 |
•Gasket kit | 1 | |
| 420641 |
•Gasket | 1 | |
| 420643 |
•Gasket | 2 | |
| 424621 |
•Gasket | 1 | |
| 424693 |
•Gasket | 6 | |
| 424694 |
•Gasket | 6 | |
| 468463 |
•Gasket | 1 | |
| 469327 |
•Gasket | 2 | |
| 469487 |
•Gasket | 1 | |
| 469823 |
•Gasket | 3 | |
| 20784537 (470939) |
•Gasket | 1 | |
| 479260 |
•Gasket | 6 | |
| 1545696 |
•Gasket | 1 | |
| 942703 |
•Gasket | 8 | |
| 947620 |
•Gasket | 17 | |
| 976929 |
•Gasket | 14 | |
| 13947282 (7011994) |
•Gasket | 2 | |
| 13947624 |
•Plane gasket | 8 | |
| 7018666 |
•Gasket | 4 | |
| 8170959 |
•Gasket | 1 | |
| 8194721 |
•Gasket | 2 | |
| 11030013 |
•Gasket | 1 | |
| 11032095 |
•Gasket | 1 | |
| 13947281 |
•Gasket | 2 | |
| 13947282 |
•Gasket | 2 | |
| 948885 |
•Plane gasket | 6 | |
13947621 |
•Plane gasket | 8 | |
| 13947625 |
•Plane gasket | 4 | |
| 13947627 |
•Plane gasket | 2 | |
| 421158 |
•Sealing ring | 1 | |
| 424983 |
•Sealing ring | 1 | |
| 468094 |
•Sealing ring | 1 | |
| 469455 |
•Sealing ring | 6 | |
| 469483 |
•Sealing ring | 2 | |
| 469846 |
•Sealing ring | 2 | |
| 470263 |
•Sealing ring | 1 | |
| 471321 |
•Sealing ring | 1 | |
| 471856 |
•Sealing ring | 6 | |
| 1542781 |
•Sealing ring | 1 | |
| 1544710 |
•Sealing ring | 4 | |
| 1675066 |
•Sealing ring | 4 | |
| 11000236 |
•Sealing ring | 1 | |
| 977015 (925092) |
•O-ring | 3 | |
| 943177 |
•O-ring | 1 | |
| 948980 |
•O-ring | 1 | |
| 949658 |
•O-ring | 1 | |
| 949659 |
•O-ring | 1 | |
| 975674 |
•O-ring | 3 | |
| 1664473 |
•O-ring | 2 | |
| 13948610 |
•O-ring | 1 | |
| 13948981 |
•O-ring | 2 | |
| 13949656 |
•O-ring | 2 | |
| 13949657 |
•O-ring | 2 | |
| 13975610 |
•O-ring | 1 | |
| 13975675 |
•O-ring | 2 |
