WHEEL LOADER VOLVO L120H
BASIC MACHINE
PROD NO 33042, L120H, S/N 15722
PROD NO 33042, L120H, S/N 15841 -
PROD NO 33042, L120H, S/N 632321 -
CAB
PROD NO. 11294118
TRANSMISSION
PROD NO. 22726, HTE206E
PROD NO. 22727, HTL206D
DRIVE AXLES
PROD NO. 56005, AWB 31, front
PROD NO. 56006, AWB 30, rear
PROD NO. 56007, AWB 30, rear. 83041
LOADER UNIT
PROD NO. 33028, LU L120H LUB
PROD NO. 33038, LU L120H LB LUB
ENGINE
Part number 17211904, 85821, D8, EU
Part number 17256093, 86022, D8, EU
Part number 17480979, 87256, D8, USA
Part number 17480983, 87257, D8, USA
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 11168089 |
Differential carrier | 1 | |
| 1 | 15169028 |
•Centre housing | 1 |
| 2 | |
••Cap | 2 |
| 3 | 310719 |
••Bushing | 4 |
| 4 | 13947695 |
••Screw | 4 |
| 5 | 13946304 |
••Washer | 4 |
| 6 | 11034156 |
•Plug | 1 |
| 7 | 958228 |
•O-ring | 1 |
| 8 | |
•Sign | 1 |
| 9 | 950891 |
•Drive screw | 2 |
| 10 | 15194310 |
•Drive gear set | 1 |
| 11 | 11102623 |
•Spider | 1 |
| 12 | 17415136 |
•Differential side gear | 2 |
| 13 | 17415862 |
•Differential side gear | 4 |
| 14 | 17203766 |
•Thrust washer | 4 |
| 15 | 11102146 |
•Thrust washer | 2 |
| 16 | 11102046 |
•Differential housing | 1 |
| 17 | 11102062 |
•Hexagon screw | 14 |
| 18 | 13946008 |
•Lock nut | 14 |
| 19 | 11102145 |
•Differential housing | 1 |
| 20 | 13979275 |
•Hexagon screw | 16 |
| 21 | 183704 |
•Roller bearing | 2 |
| 22 | 1522136 |
•Setting nut | 1 |
| 23 | 1522136 |
•Setting nut | 1 |
| 24 | 1522426 |
•Lock washer | 2 |
| 25 | 996328 |
•Flange screw | 4 |
| 26 | 914480 |
•Snap ring | 1 |
| 27 | 11035994 |
•Roller bearing | 1 |
| 28 | 11034695 |
•Shim | REQ |
| 28 | 11034696 |
•Shim | REQ |
| 28 | 11034697 |
•Shim | REQ |
| 29 | 11034828 |
•Spacer ring | REQ |
| 29 | 11034829 |
•Spacer ring | REQ |
| 29 | 11034830 |
•Spacer ring | REQ |
| 29 | 11034831 |
•Spacer ring | REQ |
| 29 | 4870247 |
•Spacer ring | REQ |
| 29 | 4870248 |
•Spacer ring | REQ |
| 29 | 4870249 |
•Spacer ring | REQ |
| 29 | 4870250 |
•Spacer ring | REQ |
| 30 | 15164989 |
•Bearing | 1 |
| 31 | 4717576 |
•Sealing ring | 1 |
| 32 | 943142 |
•Sealing ring | 1 |
| 33 | 11168056 |
•Companion flange | 1 |
| 34 | 11168081 |
••Dust cover | 1 |
| 35 | 4717504 |
•Nut | 1 |
| 36 | 382779 |
•Lock washer | REQ |
| 37 | 383992 |
•Lock washer | REQ |
