+90 552 671 32 12IGNITION AND CONTROL SYSTEM > 286/300 Cable harness, Emission After-treatment
WHEEL LOADER VOLVO L120G
BASIC MACHINE
PROD NO 33009, L120G, S/N 30001 - 31533
CAB
PROD NO. 11294047
TRANSMISSION
PROD NO. 22576, HTE206
DRIVE AXLES
PROD NO. 56005, AWB 31, front
PROD NO. 56006, AWB 30, rear
PROD NO. 56007, AWB 30, rear. 83041
LOADER UNIT
PROD NO. 33029, LU L120G LUB
PROD NO. 33039, LU 120G LB LUB, 84901
ENGINE
Part number 15165680, D8HLAE4, 84663
Part number 15083693, D8HLAE4, 85100
Part number 15165680, 85100
Part number 17230855, 86006
Part number 17231193 (replacement version)
Part number 15083693, 84663
Part number 17230854, 86007
Part number 17231191 (replacement version)
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 17212977 |
Wiring harness | 1 |
| |
•CONNECTED TO: | ||
| |
••Control module | ||
| |
••Engine Control Unit | ||
| |
••Cable harness | ||
| |
••Sensor oil level/temp | ||
| |
••Exhaust gas temp | ||
| |
••Sensor | ||
| |
••Particulate Fil | ||
| 2 | 20567739 |
•Housing | 1 |
| 3 | 20429843 |
•Housing | 1 |
| 4 | 20429842 |
•Housing | 1 |
| 5 | 20429842 |
•Housing | 1 |
| 6 | 984849 |
•Housing | 1 |
| 7 | 20429842 |
•Housing | 1 |
| 8 | 20567733 |
•Housing | 1 |
| 9 | 20737024 |
•Housing | 1 |
| 10 | 990054 |
•Housing | 1 |
| 11 | 990053 |
•Housing | 1 |
| 12 | 990051 |
•Housing | 1 |
| 13 | 4803754 |
•Hose | REQ |
| 14 | 4803755 |
•Hose | REQ |
| 15 | 11039491 |
•Hose | REQ |
| 16 | 4803746 |
•Hose | REQ |
| 17 | 4803748 |
•Hose | REQ |
| 18 | 11170006 |
•Hose | REQ |
| 19 | 11170267 |
•Hose | REQ |
| 20 | 11039849 |
•Adapter | 5 |
| 21 | 11039747 |
•Manifold | 1 |
| 22 | 11039723 |
•Manifold | 1 |
| 23 | 11039665 |
•Manifold | 1 |
| 24 | 3988328 |
Bracket | 1 |
| 25 | 13946173 |
Screw | 2 |
| 26 | 3963413 |
Ring | 1 |
| 27 | 946671 |
Flange screw | 1 |
| 28 | 13949997 |
Clamp | 1 |
| 29 | 11117464 |
Plain washer | 1 |
| 30 | 13949746 |
Clamp | 1 |
| 31 | 13945408 |
Nut | 1 |
| 32 | 969407 |
Six point socket screw | 4 |
| 33 | 949874 |
Flange lock nut | 4 |
| 34 | 930434 |
Spacer ring | 1 |
| 35 | 13949997 |
Clamp | 5 |
| 36 | 13946934 |
Screw | 1 |
| 37 | 946671 |
Flange screw | 2 |
| 38 | 13949746 |
Clamp | 2 |
| 39 | 13946173 |
Screw | 4 |
| 40 | 4881440 |
Cable tie | REQ |
| 41 | 980881 |
Cable tie | 1 |
| 42 | |
Cable harness | - |
