| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 16909172 |
Fuel tank | 1 | |
| 1 | 16908388 |
•Fuel tank | 1 |
| 2 | 945444 |
•Flange screw | 52 |
| 3 | 16869900 |
•Cover | 1 |
| 4 | 16801897 |
•Gasket | 3 |
| 5 | 984529 |
•Rivet nut | 52 |
| 6 | 16910015 |
•Hatch | 1 |
| 7 | 17206569 |
•Tank unit | 1 |
| 8 | 16885445 |
•Nipple | 1 |
| 9 | 16885443 |
•Nipple | 1 |
| 10 | 16901317 |
•Tank flap | 1 |
| 11 | 11054692 |
•Valve | 2 |
| 12 | 949329 |
•Gasket | 2 |
| 13 | 929192 |
•Plug | 1 |
| 14 | 946228 |
•Gasket | 1 |
| 15 | 975380 |
•Six point socket screw | 2 |
| 16 | 16864739 |
•Gasket | 1 |
| 17 | |
•Slide rail | 1 |
| 18 | |
•Plate | 1 |
| 19 | 15048799 |
•Strainer | 1 |
| 20 | 972264 |
•Six point socket screw | 3 |
| 21 | 11118857 |
•Filler cap | 1 |
| 22 | 16910514 |
"•Mount.kit | Fuel Tank" |
| 23 | 16888047 |
•Cover | 1 |
| 24 | 13949278 |
•Flange lock nut | 4 |
| 25 | 13946544 |
•Screw | 4 |
| 26 | 993327 |
•O-ring | 1 |
| 27 | 13949853 |
•Flange screw | 4 |
| 28 | 976927 |
•Gasket | 7 |
| 29 | 948645 |
•Flange lock nut | 3 |
| 30 | 16871814 |
Filler pipe | 1 |
| 31 | 16871522 |
Splash Shield | 1 |
| 32 | 16886503 |
Hose | 1 |
| 33 | 11059297 |
Hose clamp | 2 |
| 34 | 946173 |
Flange screw | 2 |
| 35 | 969598 |
Six point socket screw | 4 |
