YM Güç Tork - 211/220 Cylinder head 15187306 - A45G

SEÇ/NO	PARÇA KOD	PARÇA ADI	PARÇA SAYISI
	22114999	Cylinder head
		•Cylinder head	1
1		••Cylinder head	1
2	21042335	••Bearing housing	6
2		•••Cap	1
2		•••Bearing housing	1
3	950542	•••Pin	1
4		•••Pin	1
5	950562	•••Pin	2
6	21042355	••Bearing housing	1
6		•••Cap	1
6		•••Bearing housing	1
7	950542	•••Pin	1
8		•••Pin	1
9	950562	•••Pin	2
10	13975105	••Flange screw	7
11	21344753	••Screw	12
12	20412482	••Flange screw	1
13	21067953	••Valve guide	24
14	21780358	••Valve seat	12
15	22059584	••Valve seat	12
16	20981856	••Sleeve	6
17	20536487	••O-ring	6
18	24426722	•Expansion plug	6
19	960628	•Plug	1
20	13947281	•Gasket	1
21	24426721	•Expansion plug	16
22	20739057	•Inlet valve	12
23	20513285	•Exhaust valve	12
24	20554268	•Guide pin	6
25	20924435	•Valve stem seal	24
26	21326667	•Valve spring	12
27	21564308	•Valve spring	12
28	21324296	•Valve spring	12
29	8131328	•Valve spring washer	12
30	20551396	•Valve spring washer	12
30	8131835	•Valve spring washer	12
31	8170995	•Valve cotter	48
32	20845995	•Plug	1
33	1547252	•Sealing ring	1
34	1546531 (20844430)	•Lock brace	1
35	984732	•Flange screw	1
36	13968062	•Plug	1
37	13966143	•Plug	1
38	13947622	•Plane gasket	1
39	24426723	•Cap plug	5
40	21261987	•Washer	6
41	21121914	•Gasket	1
