A40D

Hemen bizi arayın yardımcı olalım

SEÇ/NO	PARÇA KOD	PARÇA ADI	PARÇA SAYISI
1		•Axle casing	1
2	11035871	•Spindle	2
3	13948511	•O-ring	2
4	966841	•Hex. socket screw	38
5	11035861	•Washer	2
6		•Multidisc brake	2
7	13960251	•O-ring	2
8	11102645 (11035973)	•Spacer ring	2
9	960242	•O-ring	2
10	11102199	•Face Sealing	2
10A	11703440	••O-ring	4
11	11035753	•Roller bearing	2
12	11035921	•Roller bearing	2
13	11102420 (11035755)	•Sealing ring	2
13A	11703441	••O-ring	4
14	11035972	•Hub	2
15	4717268	•Snap ring	2
16	11035924	•Gear ring holder	2
17	4717261	•Gear ring	2
18	11035878	•Nut	2
19	11035879	•Lock ring	REQ
	11035880	•Lock ring	REQ
20	914490	•Snap ring	2
21	11102179	•Axle shaft	1
	4870184	•Axle shaft	1
22	4717269	•Wear washer	2
23	11102300 (4717263)	•Sun gear	2
24	7044381	•Snap ring	2
25	11102910	•Wear ring	2
26	13955294	•Screw	2
27	4717665	•Striker plate	2
28	11102694 (4717744)	•Lock plate	2
29	15123158	•Wheel stud	36
30	11103195 (4870204)	•Planet carrier	2
31	980179	•Hexagon screw	78
32	4786810	•Needle bearing	6
33	11102299 (4717384)	•Planet gear	6
34	11035881	•Thrust washer	12
35	11035882	•Thrust washer	12
36	4717385	•Planet shaft	6
37	4717618	•Striker plate	6
38	970945 (13970945)	•Hexagon screw	12
39	941908	•Spring washer	12
40	951974	•Spring pin	12
41	11034156	•Plug	4
42	958228	•O-ring	4
43	11102073	•Sealing ring	4
