A40D
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 11127459 |
Engine anchorage | 1 |
| 2 | 967786 |
Flange screw | 6 |
| 3 | 979014 |
Flange nut | 2 |
| 4 | 20503551 (1622825) |
Rubber cushion | 1 |
| 5 | 15042661 (11064169) |
Nut plate | 2 |
| 6 | 4861316 |
Spacer ring | 4 |
| 7 | 13965194 |
Screw | 4 |
| 8 | 966362 (13966362) |
Flange screw | 2 |
| 9 | 11113003 |
Engine bracket | 1 |
| 10 | 11113004 |
Engine bracket | 1 |
| 11 | 968437 |
Flange screw | 12 |
| 12 | 191171 |
Pin | 2 |
| 13 | 11114264 |
Bracket | 2 |
| 14 | 13965194 |
Screw | 12 |
| 15 | 971099 (13971099) |
Flange lock nut | 12 |
| 16 | 4861316 |
Spacer ring | 12 |
| 17 | 11113002 |
Rubber element | 2 |
| 18 | 11118580 |
Spacer sleeve | 8 |
| 19 | 968437 |
Flange screw | 8 |
| 20 | 11114265 |
Washer | 2 |
| 21 | 968299 |
Flange screw | 2 |
| 22 | 13967934 |
Flange lock nut | 2 |
| 23 | |
Lifting eye | 1 |
| 24 | 959265 |
Hex. socket screw | 3 |
| 25 | |
Lifting eye | 1 |
| 26 | 975122 |
Flange screw | 4 |
| 27 | 13947790 |
Screw | 2 |
