YM Güç Tork - 463/400 Final drive 23961 - A35E

SEÇ/NO	PARÇA KOD	PARÇA ADI	PARÇA SAYISI
	17436375	Differential carrier
1	17255904	•Centre housing
2		••Cap
3		••Cap
4	966790	••Hex. socket screw
5		••Washer
6	950588	••Pin	4
	17246479	•Drive gear set	1
7		••Pinion	1
8		••Crown wheel	1
9	17437279	•Differential housing	1
10	17437430	•Differential housing	1
11	17239952	•Spider	1
12	17438016	•Thrust washer	4
13	81241442	•Flange screw	16
14	184637	•Roller bearing	2
15	11102411	•Bearing adjuster	1
16	17239358	•Adjusting nut	1
17	11102409	•Companion flange	1
18	17247173	•Dog clutch	1
19	17241744	•Fork	1
20	11000274	•Roller bearing	1
21	17239266	•Spacer sleeve	REQ
21	17293703	•Spacer sleeve	REQ
21	17293705	•Spacer sleeve	REQ
22		•Part Plate	1
23	950891	•Drive screw	2
24	13949851	•Washer	1
25	914470	•Snap ring	1
26	183688	•Roller bearing	1
27	951994	•Spring pin	2
28	941291	•Shim	REQ
28	941292	•Shim	REQ
28	941293	•Shim	REQ
29	945506	•Snap ring	1
30	17240332	•Differential side gear	2
31	17240333	•Differential pinion	4
32	1523084	•Lock brace	2
33	11168132	•Guide ring	4
34	17380348	•Bushing	2
35	17245352	•Spring	2
36	1523087	•Pin	4
37	17241558	•Piston	2
38	17418789	•Bushing	REQ
38	17420369	•Bushing	REQ
38	17420370	•Bushing	REQ
38	17420371	•Bushing	REQ
38	17420372	•Bushing	REQ
38	17420379	•Bushing	REQ
38	17420380	•Bushing	REQ
38	17420381	•Bushing	REQ
38	17420382	•Bushing	REQ
39	983499	•O-ring	4
40	17245285	•Cover	2
41	17246312	•Piston head	2
42	17406753	•O-ring	2
43	17246273	•Cover	2
44	967637	•Hex. socket screw	8
45	1522102	•Washer	1
46	17245228	•Thrust washer	2

Differential carrier

1

•Centre housing

2

••Cap

3

••Cap

4

••Hex. socket screw
