A30F
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 21576296 |
Cylinder head | 1 |
| 1 | 21576299 |
Cylinder head | |
| 2 | 21012752 |
•Bearing housing | 1 |
| 2 | 20411303 |
•Bearing housing | 6 |
| 3 | 422426 |
••Pin | 14 |
| 4 | 950542 |
••Pin | 7 |
| 5 | 13975105 |
•Flange screw | 7 |
| 6 | 20412482 |
•Flange screw | 7 |
| 7 | 20509465 |
•Valve seat | 12 |
| 7 | 20737849 |
•Valve seat | |
| 8 | 20509467 |
•Valve seat | 12 |
| 9 | 21515329 |
•Injector sleeve | |
| 9 | 20981856 |
•Sleeve | 6 |
| 10 | 20536487 |
••O-ring | 6 |
| 11 | 20905400 |
•Valve guide | 24 |
| 12 | 24426722 |
•Expansion plug | 6 |
| 13 | 24426721 |
•Expansion plug | 18 |
| 14 | 24426723 |
•Cap plug | 5 |
| 15 | 960628 |
•Plug | 1 |
| 16 | 13947281 |
•Gasket | 1 |
| 17 | 13968062 |
•Plug | 2 |
| 18 | 968060 |
•Plug | 1 |
| 19 | 20451868 |
•Plug | 1 |
| 20 | 949658 |
•O-ring | 1 |
| 21 | 946440 |
•Flange screw | 1 |
| 21 | 13946173 |
•Screw | 1 |
| 22 | 3183211 |
•Valve spring | 24 |
| 23 | 21310068 |
•Valve spring | 24 |
| 24 | 20510743 |
•Valve spring washer | 24 |
| 25 | 21990221 (20864662) |
•Valve stem seal | 24 |
| 26 | 20510747 |
•Valve cotter | 48 |
| 27 | 20540017 |
•Inlet valve | 12 |
| 27 | 20737856 |
•Inlet valve | |
| 28 | 21430918 |
•Exhaust valve | 12 |
| 29 | 20495935 |
Cylinder head gasket | 1 |
| 30 | 21345131 |
Flange screw | 26 |
| 31 | 20563234 |
Bracket | 1 |
| 32 | 13944926 |
Screw | 5 |
| 33 | 13968063 |
Plug | - |
