| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 3192086 |
Final drive | 1 | |
| 1 | 3152054 |
•Diff Carr Hsg | 1 |
| 2 | |
••Cap | 1 |
| |
••Cap | 1 | |
| 3 | 13961650 |
••Pin | 4 |
| 4 | 3152161 |
••Flange screw | 4 |
| 5 | 3152000 |
•Drive gear set | 1 |
| 6 | 3152193 |
•Differential housing | 1 |
| 7 | 81241442 |
•Flange screw | 16 |
| 8 | 3152194 |
•Lock plate | 1 |
| 9 | 81241411 |
•Bearing | 1 |
| 10 | 81241210 |
•Adjusting screw | 1 |
| 11 | 13945444 |
•Screw | 2 |
| 12 | 3152160 |
•Thrust washer | 4 |
| 13 | 3152125 |
•Differential side gear | 2 |
| 14 | 81241445 |
•Differential spider | 1 |
| 15 | 81241444 |
•Differential side gear | 4 |
| 16 | 81241447 |
•Thrust Washer | 4 |
| 17 | 3152137 |
•Differential housing | 1 |
| 18 | 3152068 |
•Roller bearing | 1 |
| 19 | 81241945 |
•Adjusting screw | 1 |
| 20 | 81241405 |
•Support bearing | 1 |
| 21 | 81241285 |
•Snap ring | 1 |
| 22 | 81241402 |
•Pinion bearing | 1 |
| 23 | 81241287 |
•Spacer sleeve | REQ |
| 81241288 |
•Spacer sleeve | REQ | |
| 81241289 |
•Spacer sleeve | REQ | |
| 24 | 11102713 |
•Pin Brg Sleeve | 1 |
| 25 | 81241461 |
•Pinion bearing | 1 |
| 26 | 3152027 |
•Seal | 1 |
| 27 | 3152058 |
•Flange screw | 10 |
| 28 | 3152059 |
•Shim | REQ |
| 3152060 |
•Shim | REQ | |
| 3152061 |
•Shim | REQ | |
| 3152062 |
•Shim | REQ | |
| 3152063 |
•Shim | REQ | |
| 3152064 |
•Shim | REQ | |
| 3152065 |
•Shim | REQ | |
| 29 | 81241239 |
•Nut | 1 |
| 30 | 11102862 |
Companion flange | 1 |
| 31 | 1673273 |
•Protecting plate | 1 |
