FRONT AXLE; REAR AXLE > 463/300 Final drive 56095

SEÇ/NO	PARÇA KOD	PARÇA ADI	PARÇA SAYISI
	17298349	Differential carrier	1
1	17239652	•Gear housing	1
2	914484	•Snap ring	1
3	1523318	•Lock washer	REQ
3	1523319	•Lock washer	REQ
4	1522293	•Nut	2
5	11036504	•Companion flange	1
6	1523124	•Sealing ring	1
7	948642	•Sealing ring	1
8	977117	•Hex. socket screw	19
9	17239687	•Bearing housing	1
10	17277977	•Shim	REQ
10	17297549	•Shim	REQ
10	17297551	•Shim	REQ
11	960256	•O-ring	1
12	7011071	•Roller bearing	1
13	17239725	•Gear	1
14	184178	•Bearing	1
15	11103069	•Dog clutch	1
16	1522355	•Washer	1
17	914480	•Snap ring	1
18	4880126	•Needle bearing	1
19	190289	•Snap ring	1
20	11103070	•Dog clutch	1
21	946329	•Flange screw	4
22	17239881	•Lock cover	1
23	960242	•O-ring	1
24	948650	•Thrust washer	1
25	17434923	•Roller bearing	1
26	384319	•Spacer Sleeve	REQ
26	384320	•Spacer Sleeve	REQ
26	384321	•Spacer Sleeve	REQ
26	384322	•Spacer Sleeve	REQ
26	384323	•Spacer Sleeve	REQ
26	384324	•Spacer Sleeve	REQ
26	384325	•Spacer Sleeve	REQ
26	384326	•Spacer Sleeve	REQ
26	384327	•Spacer Sleeve	REQ
26	384328	•Spacer Sleeve	REQ
26	384329	•Spacer Sleeve	REQ
26	384330	•Spacer Sleeve	REQ
26	384331	•Spacer Sleeve	REQ
26	384332	•Spacer Sleeve	REQ
26	384333	•Spacer Sleeve	REQ
26	384334	•Spacer Sleeve	REQ
26	384335	•Spacer Sleeve	REQ
26	384336	•Spacer Sleeve	REQ
26	384337	•Spacer Sleeve	REQ
26	384338	•Spacer Sleeve	REQ
26	384339	•Spacer Sleeve	REQ
26	384340	•Spacer Sleeve	REQ
26	384341	•Spacer Sleeve	REQ
26	384342	•Spacer Sleeve	REQ
26	384343	•Spacer Sleeve	REQ
26	384344	•Spacer Sleeve	REQ
26	384345	•Spacer Sleeve	REQ
26	384346	•Spacer Sleeve	REQ
26	384347	•Spacer Sleeve	REQ
26	384348	•Spacer Sleeve	REQ
26	384349	•Spacer Sleeve	REQ
26	384350	•Spacer Sleeve	REQ
26	384351	•Spacer Sleeve	REQ
26	384353	•Spacer Sleeve	REQ
26	384354	•Spacer Sleeve	REQ
27	17239556	•Lower gear	1
28	979819	•Hex. socket screw	5
29	1523372	•Lock brace	2
30	11168132	•Guide ring	4
31	17380348	•Bushing	2
32	17245352	•Spring	2
33	1523087	•Pin	4
34	17247192	•Fork	1
35	17241558	•Piston	2
36	17418789	•Bushing	REQ
36	17420369	•Bushing	REQ
36	17420370	•Bushing	REQ
36	17420371	•Bushing	REQ
36	17420372	•Bushing	REQ
36	17420379	•Bushing	REQ
36	17420380	•Bushing	REQ
36	17420381	•Bushing	REQ
36	17420382	•Bushing	REQ
37	983499	•O-ring	4
38	17245285	•Cover	2
39	17246312	•Piston head	2
40	17406753	•O-ring	2
41	17246273	•Cover	2
42	967637	•Hex. socket screw	8
43	15090257	•Induction sensor	1
44	976109	•O-ring	1
45	17209371	•Protecting casing	1
46	946440	•Flange screw	2
47	950675	•Pin	1
