A25E
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 20412574 |
Pipe | 1 |
| 2 | 13965186 |
Screw | 4 |
| 3 | 471956 |
Sealing ring | 4 |
| 4 | |
Oil Pump | 1 |
| 5 | 13947760 |
Screw | 4 |
| 6 | 20405083 |
Suction pipe | 1 |
| 7 | 22275838 (20451487) |
Sealing ring | 2 |
| 8 | 20405081 |
Pressure Pipe | 1 |
| 9 | 21092243 |
Sealing ring | 2 |
| 10 | 20412866 |
Valve Housing | 1 |
| 11 | 469846 |
•Sealing ring | 1 |
| 12 | 3826265 |
•Reducing Valve | 1 |
| 13 | 471648 |
•Cover | 1 |
| 14 | 946934 |
•Flange screw | 2 |
| 15 | 20412865 |
•Cover | 1 |
| 16 | 946671 |
•Flange screw | 5 |
| 1161277 |
•Sealant | 1 | |
| 17 | 21092243 |
Sealing ring | 1 |
| 18 | 13947790 |
Screw | 4 |
| 19 | 3161262 |
Oil strainer | 1 |
| 20 | 13948610 |
O-ring | 1 |
| 21 | 13973924 |
Flange screw | 2 |
| 22 | 20727702 |
Piston cooling jet | 6 |
| 23 | 13966378 |
Flange screw | 6 |
