| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 11196391 |
Fuel tank | 1 |
| 2 | 11054692 |
•Valve | 1 |
| 3 | 949329 |
•Gasket | 1 |
| 4 | 11113443 |
•Cover | 1 |
| 5 | 11196531 |
•Gasket | 1 |
| 6 | 13946173 |
•Screw | 16 |
| 7 | 15010255 (11170094) |
•Tank unit | 1 |
| 8 | 8151926 |
••O-ring | 1 |
| 9 | 11713109 |
•Nipple | 1 |
| 10 | 11713108 |
•Nipple | 1 |
| 11 | |
•O-ring | 2 |
| 12 | 11118550 |
•Strainer | 1 |
| 13 | 972264 |
•Six point socket screw | 3 |
| 14 | 11118857 |
•Filler cap | 1 |
| |
••Gasket | 1 | |
| 15 | 11190166 |
Bracket | 1 |
| 16 | 13945444 |
Screw | 2 |
| 17 | 984645 |
Plug | 2 |
| 18 | 992109 |
Hose | REQ |
| 19 | 13943474 |
Hose clamp | 2 |
| 20 | 11113355 |
Air cleaner | 1 |
| 21 | |
•Cover | 1 |
| 22 | 11707077 |
•Filter insert | 1 |
| 23 | |
•Housing | 1 |
| 24 | 943477 |
•Hose clamp | 1 |
| 25 | |
Fuel Filter | 1 |
| 26 | 13947760 |
Screw | 3 |
| 27 | 948645 |
Flange lock nut | 3 |
| 28 | 11055605 |
Plain washer | 2 |
| 29 | 11192247 |
Fuel pipe | 1 |
| |
Fuel hose | 1 | |
| 30 | 978432 |
Nipple | 1 |
| 31 | 948884 |
Gasket | 1 |
| 32 | 13946602 |
Nipple | 3 |
| |
Nipple | 4 | |
| 33 | 13945653 |
Plane gasket | 3 |
| |
Plane Gasket | 4 | |
| 34 | 11192606 |
Fuel pipe | 1 |
| |
Fuel hose | 1 | |
| 35 | 11190164 |
Fuel pipe | 1 |
| |
Fuel hose | 1 | |
| 36 | 11190162 |
Fuel pipe | 1 |
| |
Fuel hose | 1 | |
| 37 | 11192607 |
Fuel pipe | 1 |
| |
Fuel pipe | 1 | |
| 38 | 13946173 |
Screw | 1 |
| 39 | 977599 (13977599) |
Clamp | 1 |
| 40 | 948645 |
Flange lock nut | 1 |
| 41 | 4881440 |
Cable tie | REQ |
