A25D
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 11031408 |
Injection pump | 1 |
| 3095395 |
•Stop control kit | 1 | |
| 3094570 |
•Overflow valve | 1 | |
| 2 | |
•Companion flange | 1 |
| 3 | 479399 |
Washer | 2 |
| |
Companion flange | 1 | |
| 4 | 479458 |
•Companion disc | 4 |
| 5 | 479399 |
•Washer | 4 |
| 6 | 11999891 |
•Spacer | 1 |
| 7 | 478897 |
•Sleeve | 4 |
| 8 | 13965185 |
•Screw | 4 |
| 9 | 976945 |
•Washer | 4 |
| 10 | 13971095 |
•Flange nut | 4 |
| 11 | 479458 |
•Companion disc | 4 |
| 12 | 479399 |
•Washer | 2 |
| 13 | 1556186 |
•Companion flange | 1 |
| 14 | 478897 |
•Sleeve | 2 |
| 15 | 13965220 |
•Screw | 2 |
| 16 | 976945 |
•Washer | 2 |
| 17 | 13971095 |
•Flange nut | 2 |
| 18 | 478897 |
Sleeve | 2 |
| 19 | 11162454 |
Spacer sleeve | 2 |
| 20 | 13965185 |
Screw | 2 |
| 21 | 1556285 |
Screw | 1 |
| 22 | 478799 |
Bearing housing | 1 |
| 23 | 1546221 |
Sealing ring | 1 |
| 24 | 478411 |
Shaft | 1 |
| 25 | 914540 |
Retaining ring | 1 |
| 26 | 7011014 |
Ball bearing | 1 |
| 27 | 1546132 |
Stop ring | 1 |
| 28 | 184788 |
Ball bearing | 1 |
| 29 | 423123 |
Sealing ring | 1 |
| 30 | 13940159 |
Screw | 5 |
| 31 | 13941907 |
Washer | 5 |
| 32 | 478429 |
Gear | 1 |
| 33 | 471534 |
Screw | 6 |
| 34 | 942385 |
Disc spring | 6 |
| 35 | 11162592 |
Protecting plate | 1 |
| 36 | 13965175 |
Screw | 2 |
