A25C 4x4
Aradığınızı bulamıyor musunuz?
Hemen bizi arayın yardımcı olalım
+90 552 671 32 12
| SEÇ/NO | PARÇA KOD | PARÇA ADI | PARÇA SAYISI |
|---|---|---|---|
| 1 | 11991124 |
Planet carrier | 1 |
| 2 | 11991125 |
Shaft | 5 |
| 3 | 11991126 |
Wear washer | 10 |
| 4 | 11991127 |
Needle bearing | 5 |
| 5 | 11713283 (11991128) |
Planet Gear | 1 |
| 6 | 11991129 |
Lock ring | 1 |
| 7 | 11992140 |
Ring gear | 1 |
| 8 | 11991131 |
Ring gear | 1 |
| 9 | 11991132 |
Lock ring | 1 |
| 10 | 11994553 (11991133) |
Thrust washer | 1 |
| 11 | 11991134 |
Planet carrier | 1 |
| 12 | 11991135 |
Wear washer | 2 |
| 13 | 11991136 |
Wear washer | 2 |
| 14 | 11991137 |
Planet gear | 1 |
| 15 | 11991138 |
Needle bearing | 10 |
| 16 | 11991139 |
Shaft | 5 |
| 17 | 11991122 |
Sealing ring | 1 |
| 18 | 11991123 |
Sealing ring | 1 |
| 19 | 11705774 (11991121) |
Piston | 1 |
| 20 | 11993291 |
Disc | 6 |
| 1663345 |
Disc | REQ | |
| 11991118 |
Disc | REQ | |
| 21 | 11708593 (11991117) |
Disc | 6 |
| 22 | 11993291 |
Disc | REQ |
| 11991118 |
Disc | REQ | |
| 23 | 11992144 (11991140) |
Pin | 8 |
| 24 | 11991141 |
Compression spring | 8 |
| 25 | 11991142 |
Tube | 8 |
| 26 | 11992144 (11991143) |
Pin | 8 |
| 27 | 11992143 |
Thrust ring | 1 |
| 28 | 11991129 |
Lock ring | 1 |
| 29 | 11991145 |
Ring gear | 1 |
| 30 | 11991146 |
Thrust washer | 1 |
| 31 | 11991147 |
Sun gear | 1 |
| 32 | 11998594 |
Angle ring | 1 |
| 33 | 11991148 |
Shim | REQ |
11991149 |
Shim | REQ | |
| 11991150 |
Shim | REQ | |
| 11991151 |
Shim | REQ | |
| 34 | 11993291 |
Disc | REQ |
| 1663345 |
Disc | REQ | |
| 11991118 |
Disc | REQ | |
| 35 | 11708593 (11991117) |
Disc | 7 |
| 36 | 8551061 (11991152) |
Disc | 1 |
| 37 | 11998595 |
Piston | 1 |
| 38 | 11991155 |
Sealing ring | 1 |
| 39 | 1663318 |
Piston ring | 1 |
| 40 | 6633289 |
Ring | 1 |
| 41 | 184199 |
Thrust needle roller assy | 1 |
| 42 | 11991174 |
Adjusting washer | REQ |
| 11991175 |
Adjusting washer | REQ | |
| 11991176 |
Adjusting washer | REQ | |
| 11991177 |
Adjusting washer | REQ | |
| 11991178 |
Adjusting washer | REQ | |
| 43 | 11991170 |
Ring | 1 |
| 44 | 11998592 |
Shaft | 1 |
| 45 | 11991172 |
Cone | 1 |
| 46 | 11714473 (11998593) |
Ring | 1 |
